Cicada Audio Amplifier FLX1000.4
WOS Pick What this amp does in 10 seconds — expand for full specs.
- BrandCicada Audio
- SKUFLX1000.4
Mei says"Match this amp to your speakers and sub. Wrong power or wiring = weak system — do it once, do it right."
The stuff you'll actually notice
Product description
4 CHANNEL POWER AMPLIFIER
-
- 4 X 150 WRMS into 4 ohms @ 12.5 Vdc
- 4 X 168 WRMS into 4 ohms @ 14.4 Vdc
- 4 X 220 WRMS into 2 ohms @ 12.5 Vdc
- 4 X 254 WRMS into 2 ohms @ 14.4 Vdc
BRIDGED MONO – 2 CHANNEL
- 2 X 461 WRMS into 4 ohms @ 12.5 Vdc
- 2 X 530 WRMS into 4 ohms @ 14.4 Vdc
- Frequency response – 20-20,000 +/- 3dB THD < 0.5%
- Operating Voltage: 8V – 16V
- Current Draw (Music): 60 A
- Current Draw (Max): 116 A
- Recommended Fuse (Music): 120 A
- Total Efficiency: 79%
- Damping Factor: 200
- SNR: 91dB
- Crossover LPF/FULL/HPF: 30 TO 300Hz
- Slope:12dB per octave
- Gain: 0.2V – 12 Vac
- Turn-On Configuration: REM/DC
- THD + N (10% Rated Power): 0.1%
- Product Dimensions (Inches / Millimeters): 6.0 x 4.9 x 2.0 in / 152 x 124 x 51 mm
Power breakdown
Inputs, filters & control
Build, wiring & install
Protection & performance
Full specifications
Amplifier
Power ratings
Inputs & filters
Wiring
Weather / environment
Support
Support & warranty
Need help choosing or installing?
We build indestructible, IP-rated systems for marine, motorcycle, UTV, and automotive. If you want a matched setup, we’ll guide you to the right gear the first time.
