DB Drive Car Audio EX6NPS-CF-65
- 1.5″ (38.1mm) Midrange voice coil
- High-intensity NEO ring magnet
- IP65 rated weather resistant Carbon fiber cone
- Cloth surround
- Stamped steel basket
- Wide dispersion 1″ aluminum dome tweeter
- Protective grill
| T/S PARAMETERS | |
|---|---|
| Resonant Frequency (fs) | 82.9Hz |
| D.C. Voice Coil Resistance (Re) | 3.2Ω |
| Mechanical Quality Factor (Qms) | 7.03 |
| Electrical Quality Factor (Qes) | 0.38 |
| Total Quality Factor (Qts) | 0.36 |
| Compliance Equivalent Volume (Vas) | 5.0L |
| Mechanical Compliance (Cms) | 0.20 mm/N |
| REPLACEMENT DIAPHRAGM: |
|---|
| ADDITIONAL SPECS | |
|---|---|
| Nominal Impedance | 4Ω |
| Power Handling | 225 Watts |
| Dynamic Wattage | 450 Watts |
| Sensitivity (1w/1m) | 90.6 dB |
| Frequency Response | 82Hz – 19KHz |
| DIMENSIONS | |
|---|---|
| Mounting Depth: | 2.8″ (71.2mm) |
| Cutout Diameter: | 5.78″ (147mm) |
