DB Drive

DB Drive Car Audio EX8NMB-CFX2

DB Drive Car Audio EX8NMB-CFX2

$1,299.90 USD
$1,299.90 USD
Sale Sold out
WEATHER READY
  • IP RatingsIP65
View full details
Mei from Wide Open Sound

Wide Open Sound · Curated gear

DB Drive Car Audio EX8NMB-CFX2

WOS Pick What you're getting in 10 seconds — expand for full details.

  • BrandDB Drive
  • SKUEX8NMB-CFX2
  • IPIP65
Mei says

"Match gear to your install and power budget. Do it once, do it right."

The stuff you'll actually notice
  • The XPERT EX8NMB-CFv2 carbon fiber midbass driver is engineered for compact installations with its redesigned single-ring N52 neodymium magnet and custom aluminum die-cast basket. Built with carbon fiber for enhanced outdoor durability, its motor provides an extended bandwidth...
Product description

The XPERT EX8NMB-CFv2 carbon fiber midbass driver is engineered for compact installations with its redesigned single-ring N52 neodymium magnet and custom aluminum die-cast basket. Built with carbon fiber for enhanced outdoor durability, its motor provides an extended bandwidth, making it an ideal match for pairing with midranges and tweeters.

FEATURES:

  • 8" Neo Carbon Fiber 2- Way Midbass
  • 2.0" (51mm) Midrange Voice Coil
  • Neodymium Ring Magnet Assembly
  • IP65 Rated Weather Resistant Carbon Fiber Cone
  • Die-Cast Aluminum Basket with Radial Venting

SPECIFICATIONS:

Power Handling 300 Watts
Dynamic Wattage 600 Watts
Resonant Frequency (fs) 68.074 Hz
D.C. Voice Coil Resistance (Re) 4Ω
Mechanical Quality Factor (Qms) 1.982
Electrical Quality Factor (Qes) 0.374
Total Quality Factor (Qts) 0.315
Compliance Equivalent Volume (Vas) 10.331 L
Mechanical Compliance (Cms) 189.252 mm/N
Sensitivity (1w/1m) 99.3 dB
Impedance 4Ω

DIMENSIONS:

Mounting Depth 3.78"/ 96 mm
Cutout Diameter 7.09"/ 180 mm



(SOLD IN PAIRS)



Weather & environment
IP Ratings IP65
