DS18 Marine Amplifier NXL-N1

DS18 Marine Amplifier NXL-N1

Regular price $335.95 USD
Regular price Sale price $335.95 USD
Sale Sold out
WEATHER READY
  • IP RatingsIP67
Quantity
✔ In Stock & Ready To Ship
View full details
Mei from Wide Open Sound

Wide Open Sound · Curated gear

DS18 Marine Amplifier NXL-N1

WOS Pick What this amp does in 10 seconds — expand for full specs.

  • BrandDS18
  • SKUNXL-N1
Mei says

"Match this amp to your speakers and sub. Wrong power or wiring = weak system — do it once, do it right."

The stuff you'll actually notice
Product description

DS18 HYDRO NXL-N1 Nano Digital Marine 1-Channel Monoblock Boat, ATV, UTV Amplifier 1050 Watts


Whether you are the type of audio enthusiast that likes to hit the open road on his bike, ride the rough trails on your side by side, or cruise the open waters, you are going to need a powerful and waterproof rated amp that has a small footprint and also make great power.

DS18 has a line just for the job with the NXL series of amplifiers to power your whole system. These amps are very efficient, small, and have great power output. These amps come in 1 channel, 2 channel, 4 channel, and 5 channels to help you accommodate for all your different speaker setups without having to look further.

All units have stable and reliable 4-layer PCB layouts, IPX67 rated for power sports, has an ultra-compact size for easy installation, and has audio precision quality control verification. The NXL line of amps is what the serious outdoors person will need for their vehicle hands down!

AMPLIFIERS ARE NOT FOR SUBMERSIBLE USE, WILL VOID WARRANTY

Highlights

  • Stable and reliable 4 layers PCB layout design
  • IPX67 Waterproof for Powersports applications
  • Ultra compact size for easy installation
  • Audio precision quality control verification
    Technical Details

    Model: NXL-N1
    Number of Channels: 1
    Max Power 1050W
    Frequency Response: 50Hz - 250Hz
    1 Ohm RMS Power (14.4V) Per Channel: 1 x 350W
    2 Ohms RMS Power (14.4V) Per Channel: 1 x 230W
    4 Ohms RMS Power (14.4V) Per Channel: 1 x 140W
    Input Sensitivity: 0.2V + 10V
    Low Pass Filter: 50Hz - 250Hz
    Signal-to-Noise Ratio: 90dB
    Product Dimensions: (L x W x H) 200 x 93.4 x 39.8
    Power breakdown
    Inputs, filters & control
    Build, wiring & install
    Protection & performance
    Full specifications
    Amplifier
    Power ratings
    Inputs & filters
    Wiring
    Weather / environment
    IP Ratings IP67
    Support
    Vehicle fitment
    Model NXL-N1
    Support & warranty

    Need help choosing or installing?

    We build indestructible, IP-rated systems for marine, motorcycle, UTV, and automotive. If you want a matched setup, we’ll guide you to the right gear the first time.
