Kicker Car Amplifier 46CXA3604

Kicker Car Amplifier 46CXA3604

Regular price $229.99 USD
Regular price Sale price $229.99 USD
Sale Sold out
Quantity
View full details
Mei from Wide Open Sound

Wide Open Sound · Curated gear

Kicker Car Amplifier 46CXA3604

WOS Pick What this amp does in 10 seconds — expand for full specs.

  • BrandKicker
  • SKU46CXA3604
  • Channels4
Mei says

"Match this amp to your speakers and sub. Wrong power or wiring = weak system — do it once, do it right."

The stuff you'll actually notice
  • 4-channel platform.
Product description

The CXA360.4 Four-Channel Amplifier is built to power all your door speakers in a single, powerful package.

Flexible and Fun

  • Class A/B full-range channels
  • Three-second turn-on/off delay to eliminate unwanted interference
  • Variable 12dB crossovers provides control to dial in perfect sound
  • KickEQ™ 6dB variable bass boost for those additional low frequencies
  • FIT+™ (Fail-safe Integration Technology-PLUS) means it works with nearly every radio
  • Accepts up to 40-volt input signal
  • Small footprint for easier installation
  • Vertical mounting hardware included for another unique look
  • Compatible with CXARC Remote Bass Control (AMP2 must be in LO-PASS X-OVER mode)

Using Class A/B power, this amp features a variable bass boost with KickEQ™, giving you as much as a 6dB of extra bump. A powerful 12dB crossover is also included, letting you quickly tune your system to perfection.

CX-Series Amplifiers accept up to 40 volts (400 watts) of speaker-level input signal. This kind of flexibility both makes line-out converters unnecessary and optimizes your sound quality at the same time!

Highly efficient heat sinks keep the amp cool with a sophisticated new look, while KICKER’s FIT+™ (Fail-safe Integration Technology-PLUS), gives you outstanding noise rejection - even with premium factory audio systems.

This CX-Series Amplifier delivers as much as 90 watts into four full-range channels, or 180 watts into two bridged channels. See below for more details.

Specifications

MODEL CXA360.4
Power (watts/ch) 4 Ohm Stereo 65x4
Power (watts/ch) 2 Ohm Stereo 90x4
Power (watts/ch) 4 Ohm Mono 180x2
CXARC Remote Bass Capable (sold sep.) Yes
Dimensions (in, cm): (all models 2-3/8, 5.9H x 6-3/4, 17W x ...L) 12-1/2, 31.7
Frequency Response (Hz) 10Hz-20kHz
Input Sensitivity 125mV–5V (Low Level) 1V–40V (High Level)
Signal-to-Noise Ratio 95dB
Active Crossover HI, LO or OFF; Variable 50–200Hz @ 12dB/Octave
Subsonic Filter n/a
KickEQ™ Boost Variable 0-6dB @40Hz
Power breakdown
Inputs, filters & control
Build, wiring & install
Protection & performance
Full specifications
Amplifier
Amp Channels 4
Power ratings
Inputs & filters
Wiring
Weather / environment
Support
Vehicle fitment
Model 46CXA3604
Support & warranty

Need help choosing or installing?

We build indestructible, IP-rated systems for marine, motorcycle, UTV, and automotive. If you want a matched setup, we’ll guide you to the right gear the first time.
