SounDigital Amplifier 12000.1EVOX-1O
WOS Pick What this amp does in 10 seconds — expand for full specs.
- BrandSounDigital
- SKU12000.1EVOX-1O
Mei says"Match this amp to your speakers and sub. Wrong power or wiring = weak system — do it once, do it right."
The stuff you'll actually notice
Product description
TECHNICAL SPECIFICATIONS
12000.1 EVOX – 1Ω
Power @ 12.6V @ 4Ω: 1 X 5227 WRMS
Power @ 12.6V @ 2Ω: 1 X 7920 WRMS
Power @ 12.6V @ 1Ω: 1 X 12000 WRMS
Power @ 14.4V @ 4Ω: 1 X 5828 WRMS
Power @ 14.4V @ 2Ω: 1 X 8831 WRMS
Power @ 14.4V @ 1Ω: 1 x 13380 WRMS
Operating Voltage: 8V – 16V
Current Draw (Music): 627 A
Current Draw (Max): 1253 A
Recommended Fuse (Music): 2 X 350 A
Total Efficiency: 76%
Damping Factor: 200
Frequency Response (-3dB): 5Hz – 500Hz
SNR: 76dB
Crossover HPF: 5Hz – 30Hz
Crossover LPF: 50Hz – 500Hz
THD + N (10% Rated Power): 0.1%
Product Dimensions: 20.8 x 8.8 x 2.8 in
Product Dimensions: 53.0 x 22.5 x 7.1 cm
12000.1 EVOX – 2Ω
Power @ 12.6V @ 4Ω: 1 X 7920 WRMS
Power @ 12.6V @ 2Ω: 1 X 12000 WRMS
Power @ 12.6V @ 1Ω: N/A
Power @ 14.4V @ 4Ω: 1 X 8831 WRMS
Power @ 14.4V @ 2Ω: 1 X 13380 WRMS
Power @ 14.4V @ 1Ω: N/A
Operating Voltage: 8V – 16V
Current Draw (Music): 627 A
Current Draw (Max): 1253 A
Recommended Fuse (Music): 2 X 350 A
Total Efficiency: 76%
Damping Factor: 200
Frequency Response (-3dB): 5Hz – 500Hz
SNR: 76dB
Crossover HPF: 5Hz – 30Hz
Crossover LPF: 50Hz – 500Hz
THD + N (10% Rated Power): 0.1%
Product Dimensions: 20.8 x 8.8 x 2.8 in
Product Dimensions: 53.0 x 22.5 x 7.1 cm
Power breakdown
Inputs, filters & control
Build, wiring & install
Protection & performance
Full specifications
Support & warranty
Need help choosing or installing?
We build indestructible, IP-rated systems for marine, motorcycle, UTV, and automotive. If you want a matched setup, we’ll guide you to the right gear the first time.
