SounDigital Amplifier 20000.1EVOX-1O

Name: SounDigital Amplifier 20000.1EVOX-1O
Brand: SounDigital
SKU: 20000.1EVOX-1O
Price: 2999.99 USD
Availability: OutOfStock

$2,999.99 USD

~~$3,299.99 USD~~ $2,999.99 USD

Sale Sold out

View full details

Wide Open Sound · Curated gear

SounDigital Amplifier 20000.1EVOX-1O

WOS Pick What this amp does in 10 seconds — expand for full specs.

BrandSounDigital
SKU20000.1EVOX-1O

Mei says
"Match this amp to your speakers and sub. Wrong power or wiring = weak system — do it once, do it right."

The stuff you'll actually notice

Product description

The EVO X Line brings the latest technology in a compact design with the highest quality components. From a pioneering technology, SounDigital brought to car audio amplifiers something that had not been explored yet. The thermal coupling through RTGP system.

The exclusive RTGP system (Thermal Recovery for power generation) assures SounDigital products both greater thermal efficiency and robustness with higher stability.

TECHNICAL SPECIFICATIONS

20000.1 EVOX – 1Ω
Power @ 12.6V @ 4Ω: 1 X 8712 WRMS
Power @ 12.6V @ 2Ω: 1 X 13200 WRMS
Power @ 12.6V @ 1Ω: 1 X 20000 WRMS
Power @ 14.4V @ 4Ω: 1 X 9714 WRMS
Power @ 14.4V @ 2Ω: 1 X 14718 WRMS
Power @ 14.4V @ 1Ω: 1 X 22300 WRMS
Operating Voltage: 8V – 16V
Current Draw (Music): 980 A
Current Draw (Max): 1960 A
Recommended Fuse (Music): 1200 A
Total Efficiency: 81%
Damping Factor: 200
Frequency Response (-3dB): 5Hz – 500Hz
SNR: 76dB
Crossover HPF: 5Hz – 30Hz
Crossover LPF: 50Hz – 500Hz
THD + N (10% Rated Power): 0.2%
Product Dimensions: 34 x 8.8 x 2.8 in

Power breakdown

Inputs, filters & control

Build, wiring & install

Protection & performance

Full specifications

Amplifier

Power ratings

Inputs & filters

Wiring

Weather / environment

Support

Support & warranty

Need help choosing or installing?

We build indestructible, IP-rated systems for marine, motorcycle, UTV, and automotive. If you want a matched setup, we’ll guide you to the right gear the first time.
