Blaze Audio PowerZone Connect 1008 BZ-PowerZoneCT-1008
WOS Pick What you're getting in 10 seconds — expand for full details.
- BrandBlaze Audio
- SKUBZ-PowerZoneCT-1008
Mei says"Match gear to your install and power budget. Do it once, do it right."
The stuff you'll actually notice
- Description PowerZone Connect 1008 --1U - 8 channel 1000W 8 Ohm and 70v - IP Amplifier with DSP The PowerZone™ Connect 1U series is a line of DSP-enabled Class-D amplifiers designed to make system installers’ lives easier, offering unparalleled reliability and efficiency, al...
Product description
Description
PowerZone Connect 1008 --1U - 8 channel 1000W 8 Ohm and 70v - IP Amplifier with DSP
The PowerZone™ Connect 1U series is a line of DSP-enabled Class-D amplifiers designed to make system installers’ lives easier, offering unparalleled reliability and efficiency, along with exceptional system configuration. The amplifiers have built-in Wireless-Access-Point for simple connection and easy system setup via Wi-Fi.
- 1RU form factor
- Full-matrix DSP configuration via PowerZone™ Control web app (built-in)
- Hybrid power distribution in both Lo-Z and Hi-Z
- Powered by Pascal UMAC™ Class-D technology
- Flexible power sharing across output channels
- S/PDIF input/output
- Configurable GPIO
- ErP and Energy Star compliant
- UL listed audio equipment
- UREC™ universal power supply with PFC
- 5 Year warranty
| Output Power @ 4/8Ω | 8 x 125 W |
| Output Power @ 70/100V* | 4 x 250 W |
| Total System Power | 1000 W |
| Power Consumption | 300 W |
| Dimensions | 44 x 440 x 319 mm 1.7 x 17.3 x 12.6 in |
| Weight | 3.8 kg | 8.4 lbs |
Weather & environment
Vehicle fitment
| Model | BZ-PowerZoneCT-1008 |
|---|
