Blaze Audio PowerZone Connect -Dante-20 BZ-PowerZoneCT-6008D
WOS Pick What you're getting in 10 seconds — expand for full details.
- BrandBlaze Audio
- SKUBZ-PowerZoneCT-6008D
Mei says"Match gear to your install and power budget. Do it once, do it right."
The stuff you'll actually notice
- Description PowerZone™ Connect 6008D (LBX-888-011)6000 W DSP-enabled Class-D amplifier with 8 channels and Dante™ Full rack 2U form factor Full-matrix DSP configuration via PowerZone™ Control web app (built-in) Hybrid power distribution in both Lo-Z and Hi-Z Powered by...
Product description
Description
PowerZone™ Connect 6008D (LBX-888-011)
6000 W DSP-enabled Class-D amplifier with 8 channels and Dante™
- Full rack 2U form factor
- Full-matrix DSP configuration via PowerZone™ Control web app (built-in)
- Hybrid power distribution in both Lo-Z and Hi-Z
- Powered by Pascal UMAC™ Class-D technology
- Dante™ Ultimo™ chip 4×4 (4-channels)
- UREC™ universal power supply with PFC
- S/PDIF input/output
- Configurable GPIO
- ErP and Energy Star compliant
- UL listed audio equipment
- 5 Year warranty
| Channels | 8 x Lo-Z/4 x Hi-Z |
| Output Power @ 2 Ω | 8 x 750 W (SE) |
| Output Power @ 4 Ω | 8 x 750 W (SE) 4 x 1500 W (BTL) |
| Output Power @ 8 Ω | 8 x 400 W (SE) 4 x 1500 W (BTL) |
| Output Power @ 70 V | 4 x 1200 W (BTL) |
| Output Power @ 100 V | 4 x 1500 W (BTL) |
| Total System Power | 6000 W |
Weather & environment
Vehicle fitment
| Model | BZ-PowerZoneCT-6008D |
|---|
