DB Drive Car Audio EWXPW10D4
WOS Pick What you're getting in 10 seconds — expand for full details.
- BrandDB Drive
- SKUEWXPW10D4
Mei says"Match gear to your install and power budget. Do it once, do it right."
The stuff you'll actually notice
- Euphoria EWXPW10D4 ** Mounting depth only 5.55" Great option for full size sub in bags with restricted mounting depth. 3″ High-temperature voice coil 145 oz. ceramic ferrite magnet High-grade Low Carbon steel on top and bottom plate Designed to optimize SPL performance H...
Product description
-
Euphoria EWXPW10D4
** Mounting depth only 5.55" Great option for full size sub in bags with restricted mounting depth.
- 3″ High-temperature voice coil
- 145 oz. ceramic ferrite magnet
- High-grade Low Carbon steel on top and bottom plate
- Designed to optimize SPL performance
- High excursion spider designed
- 1.5″ high roll foam surround
- Large gauge push button speaker terminals
- Dual 4 ohm voice coils
GENERAL SPECIFICATIONS Structure 10″ (25.4cm) Woofer Dynamic Power Handling 1500 Watts Nominal Power Handling 500 Watts Impedance Dual 4Ω Voice Coil PARAMETERS Resonant Frequency (fs) 28.356Hz D.C. Voice Coil Resistance (Re) 6.54Ω Mechanical Quality Factor (Qms) 10.212 Electrical Quality Factor (Qes) 0.365 Total Quality Factor (Qts) 0.352 Equivalent Air Volume to Cms (Vas) 4.3 L Mass of Diaphragm/Coil (Mms) 116.580 g Force Factor (Bl) 19.298 N/A Sound Pressure Level (SPL) 86.463 dB *Recommended enclosure 1.0 cubic feet ported
