DS18

DS18 Marine Amplifier NXL-N2

DS18 Marine Amplifier NXL-N2

Regular price $335.95 USD
Regular price Sale price $335.95 USD
Sale Sold out
WEATHER READY
  • IP RatingsIP67
Quantity
✔ In Stock & Ready To Ship
View full details
Mei from Wide Open Sound

Wide Open Sound · Curated gear

DS18 Marine Amplifier NXL-N2

WOS Pick What this amp does in 10 seconds — expand for full specs.

  • BrandDS18
  • SKUNXL-N2
Mei says

"Match this amp to your speakers and sub. Wrong power or wiring = weak system — do it once, do it right."

The stuff you'll actually notice
Product description

DS18 HYDRO NXL-N2 Nano Full-Range Digital Marine 2-Channel Boat, ATV, UTV Amplifier 2 X 100 Watt @ 4 Ohm RMS 900 Watts Peak

Whether you are the type of audio enthusiast that likes to hit the open road on his bike, ride the rough trails on your side by side, or cruise the open waters, you are going to need a powerful and waterproof rated amp that has a small footprint and also make great power.

DS18 has a line just for the job with the NXL series of amplifiers to power your whole system. These amps are very efficient, small, and have great power output. These amps come in 1 channel, 2 channel, 4 channel, and 5 channels to help you accommodate for all your different speaker setups without having to look further.

Being full range amps, these can be run on subs, mids, or tweeters because of the internal design of the amp. All units have stable and reliable 4-layer PCB layouts, IPX67 rated for power sports, has an ultra-compact size for easy installation, and has audio precision quality control verification. The NXL line of amps is what the serious outdoors person will need for their vehicle hands down!

AMPLIFIERS ARE NOT FOR SUBMERSIBLE USE, WILL VOID WARRANTY

Highlights

  • Stable and reliable 4 layers PCB layout design
  • IPX67 Waterproof for Powersports applications
  • Ultra-compact size for easy installation
  • Audio precision quality control verification
  • Selectable X-Over: LPF / FULL / HPF
Technical Details

Model: NXL-N2
Number of Channels: 2
Max Power 900W
Frequency Response: 20Hz - 20KHz
2 Ohms RMS Power (14.4V) Per Channel: 2 x 150W
4 Ohms RMS Power (14.4V) Per Channel: 2 x 100W
4 Ohms RMS Power Bridge (14.4V) Channel: 1 x 300W
Input Sensitivity: 0.2V + 10V
High Pass 40Hz - 500Hz
Signal-to-Noise Ratio: 90dB
Product Dimensions: (L x W x H) 200 x 93.4 x 39.8
Power breakdown
Inputs, filters & control
Build, wiring & install
Protection & performance
Full specifications
Amplifier
Power ratings
Inputs & filters
Wiring
Weather / environment
IP Ratings IP67
Support
Vehicle fitment
Model NXL-N2
Support & warranty

Need help choosing or installing?

We build indestructible, IP-rated systems for marine, motorcycle, UTV, and automotive. If you want a matched setup, we’ll guide you to the right gear the first time.
