Powerbass Marine amplifier XL-2305MX

PowerBass XL-2305MX 300 Watt x 2 @ 2 ohm IPX65 2-Channel Powersports Amplifier

We are a Powerbass authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!

What's Inside?

•2-Channel powersport amplifier
•Remote level control
•17' Remote cable
•AGU Fuse holder
•60-amp AGU fuse (installed)
•(4) 3/4" Screws
•(2) 1/2" Screws
•2.5mm Allen wrench
•Owner's manual

Rugged Construction and Versatile Features

The PowerBass XL-2305MX is a compact and powerful 2-channel marine amplifier designed to deliver exceptional audio performance on your boat. With its rugged construction and versatile features, this amplifier enhances your marine audio system for a more enjoyable boating experience.

Clear Sound Reproduction

The XL-2305MX boasts a maximum power output of 600 watts, with 300 watts RMS per channel at 2 ohms. This ensures powerful and clear sound reproduction, allowing you to enjoy your music deeply and precisely.

Water-resistant Design and Corrosion-resistant Components

Built specifically for marine use, the XL-2305MX features a water-resistant design and corrosion-resistant components, ensuring durability and longevity in harsh marine environments. It can withstand water, humidity, and UV exposure challenges without compromising performance.

High-pass and Low-pass Crossover

This amplifier offers versatile tuning options, including adjustable gain controls and a selectable high-pass and low-pass crossover. These features allow you to customize the audio to your preferences and optimize the performance of your marine audio system.

Sleek Design and Powerful Output

With its compact size and easy installation, the XL-2305MX is suitable for boats with limited space. Its sleek design and powerful output make it an excellent choice for upgrading your boat's audio system and enjoying high-quality sound while out on the water.

Combines Power, Durability, and Flexibility

The PowerBass XL-2305MX is a reliable and versatile marine amplifier that combines power, durability, and flexibility. Whether you're cruising or anchored, this amplifier delivers exceptional sound quality and enhances your boating experience.

SPECIFICATIONS

Maximum Power : 300 Watts

Low Frequency Response : 10 Hz

High Frequency Response : 40 Hz

Number of Channels : 2

Frequency Response : 10-40 Hz

Built In Crossovers : Yes

RMS Power Output : 150 Watts

Channel Separation : Yes

Amplifier Class : D

Promo : Yes

FEATURES

Features:

IPX67 Water Resistant Sealed Design
Aluminum Die-Cast end caps with integrated input / output connectors
1200 Watt High Efficiency Full-Range Class D Design
2-OHM Stable Stereo Amplifier
International Rectifier® Chip Set
Ultra Low Current Draw
4-Layer Copper Plated PCB
Conformal Coated PC Board
PWM MOSFET Power Supply
Digital Sound Optimization Circuitry
High Damping Control Circuit
High Current Voltage Ripple Rejection Circuitry
3.5mm AUX Input
3.5mm AUX Output
Remote Soft Delay Turn On/Off Circuit
Variable Low/High Pass Electronic Crossover
Variable 18dB Bass Boost EQ
Variable Gain Control
Protection Circuit: Impedance Over-load, Speaker Short, Circuit, Thermal Overheating, and DC Output.
Remote Gain Control Included


Specifications

Selectable Subwoofer EQ: 0-18d B Gain @ 45Hz, Rear Ch.
Variable Subsonic Freq: N/A
Inputs: RCA (speaker level compatible)/3.5mm Mini Jack Input
Equalization Boost/Cut: 0 - 18 dB
Subwoofer Frequency Range: 10 Hz - 400Hz
Power Supply: Unregulated PWM
Height: 1.8"
Width: 4.6"
Depth: 8.5"
4-ohm Mono Power: 600 watts x 1
4-ohm Power: 150 watts x 2
1-ohm Mono Power: N/A
2-ohm Power: 300 watts x 2
Subwoofer EQ Frequency: 45 Hz
Low-Pass Crossover Freq: 40 Hz - 400 Hz
High-Pass Crossover Freq: 40 Hz - 400 Hz
Peak Power: 1200 watts
Crossover Slope: 12 dB
Dimensions (in Inches): 8.5" x 4.6" x 1.8"
Input Sensitivity: 0.25 V - 10.0 V
S/N Ratio: >85 dB
Total Harmonic Distortion: 0.04% at Rated Power
Strapped Output Power @ 2ohms: N/A
Output Power (14.4 V) @ 4 ohm: 150 watts x 2
Output Power (14.4 V) @ 2 ohm: 300 watts x 2
Output Power (14.4 V) @ 1 ohm: N/A
Channels (mono): 4
Frequency Response: 10 Hz - 40 kHz



UPC: 823871008292
Weight: 5
Authorized Internet Dealer




Warranty: 2 Year(s) Warranty.This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.


Do you own this product?
Write a review!






Using it in bridge mode, and connected my marine sub into it. Its good, and its got some power. But I think its not that much to push a much larger or powerful sub. But for now, I will still use this until I will upgrade for new subs and amp







Leonel

3/14/2024
